母线是电气系统中用于分配大电流的导体。母线由铜或铝制成，可连接多个电路，实现高效、安全的电力分配。母线可用于配电盘、变压器、断路器、工业厂房和变电站。它们为多个电路供电提供集中连接点，确保电力的均匀分布。这些组件受 IEC 61439、UL 891、DIN 43671 和 BS 159 等国际标准的约束，这些标准规定了母线系统的设计、制造和测试，以确保安全性和长期可靠性。西门子（Siemens）、魏德米勒（Weidmüller）和菲尼克斯电气（Phoenix Contact）等知名制造商以及其他领先制造商都在 3Dfindit 上提供包括母线在内的3D CAD模型。
