ZWKE/HR-14-85-6-6
1/5
Size
SIZE
Torque
TKN [Nm]
Total length
L [mm]
Distance between shaft ends
DBSE [mm]
Outside diameter
A [mm]
Keyway (DIN 6885)
N
Bore diameter ØH7
D1 [mm]
Bore diameter ØH7
D2 [mm]
Hub length
LN [mm]
Clamping length
LO [mm]
Basic dimension
L1 [mm]
Basic dimension
L2 [mm]
Tube diameter
R [mm]
Interference diameter
B [mm]
Basic dimension
K [mm]
Basic dimension
H [mm]
Screw (ISO 4762)
S
Installation torque per screw
TA [Nm]
1
2
3
4
5
6
7
14
12.5
85
51.8
30
6.0
6.0
36.0
16.6
20
13
30
33.0
7.5
10.5
M4
5
19
17
135
97.8
40
8.0
8.0
51.5
18.6
25
16
40
45.0
8.5
15.5
M5
11
24
60
165
101.0
55
10.0
10.0
73.0
32.0
40
18
50
58.5
15.0
21.0
M6
19
28
160
205
131.0
65
15.0
15.0
77.5
37.0
47
20
60
70.0
17.5
24.0
M8
42
38
325
250
166.0
80
15.0
15.0
96.5
42.0
55
24
75
86.0
20.0
30.0
M10
83
42
450
265
195.0
95
19.0
19.0
98.0
35.0
50
26
90
95.0
18.0
35.0
M10
83
48
525
285
181.0
105
25.0
25.0
118.0
52.0
65
28
100
105.0
25.0
38.0
M12
145
RINGSPANN StS - ZWKE/HR
| 简短文本 | Intermediate Shaft Coupling with split clamping hub - elastomer version |
| 上次修改 | 07.07.2025 11:22:40 |
