WKE/N-5-2-2-98
1/5
Size
SIZE
Torque
TKN [Nm]
Total length
L [mm]
Outside diameter
A [mm]
Keyway (DIN 6885)
N
Bore diameter ØH7
D1 [mm]
Bore diameter ØH7
D2 [mm]
Basic dimension
D3 [mm]
Elastomer insert
Z [ShA]
Basic dimension
L1 [mm]
Basic dimension
L2 [mm]
Basic dimension
L3 [mm]
Interference diameter
B [mm]
Basic dimension
K [mm]
Basic dimension
H [mm]
Screw (ISO 4762)
S
Installation torque per screw
TA [Nm]
Mass moment of inertia
J [kg cm^2]
1
2
3
4
5
6
7
8
9
10
11
12
5
0.9
15
10
2.0
2.0
-
98
5
5
-
11.5
2.5
3.5
M1.6
0.3
0.0004
7
2.0
22
14
3.0
3.0
-
98
7
8
-
16.0
3.5
5.0
M2
0.5
0.0020
9
5.0
30
20
5.0
5.0
-
98
10
10
-
23.0
5.0
7.3
M2.5
1.3
0.0110
14
12.5
35
30
6.0
6.0
-
98
11
13
-
32.0
5.0
11.0
M3
2.0
0.0630
19
17.0
66
40
8.0
8.0
-
98
25
16
-
45.0
11.0
14.5
M6
19.0
0.3700
24
60.0
78
55
10.0
10.0
-
98
30
18
-
57.0
10.5
20.0
M6
19.0
1.6500
28
160.0
90
65
15.0
15.0
-
98
35
20
-
70.5
11.0
24.5
M8
42.0
3.9100
38
325.0
114
80
15.0
15.0
-
98
45
24
-
83.0
15.5
30.0
M8
42.0
10.6400
42
450.0
126
95
19.0
19.0
85
98
50
26
28
91.0
18.0
32.5
M10
83.0
48.0000
48
525.0
140
105
25.0
25.0
95
98
56
28
32
104.0
21.0
36.0
M12
145.0
81.7500
55
685.0
160
120
35.0
35.0
110
98
65
30
37
118.0
26.0
42.5
M12
145.0
156.8000
65
900.0
185
135
40.0
40.0
115
92
75
35
47
123.0
33.0
45.0
M12
145.0
297.7000
RINGSPANN StS - WKE/N
