WKE-D/ST-14-B-5-B-5-92
1/5
Size
SIZE
Torque
TKN [Nm]
Total length
L [mm]
Outside diameter
A [mm]
Keyway (DIN 6885)
N
Hub version
VER
Bore diameter ØH7
D1 [mm]
Bore diameter ØH7
D2 [mm]
Basic dimension
D3 [mm]
Basic dimension
D4 [mm]
Elastomer insert
Z [ShA]
Basic dimension
L1 [mm]
Basic dimension
L2 [mm]
Basic dimension
L3 [mm]
Basic dimension
L4 [mm]
Basic dimension
K [mm]
Screw (ISO 4029)
S
Material for hub
MAT1
1
2
3
4
5
6
7
8
9
10
11
12
14
7.5
35
30
B-B
5.0
5.0
-
-
92
11
13
-
-
5
M4
Steel
19
10.0
66
40
A-A
6.0
6.0
32
39
92
25
16
20
20
10
M5
Steel
24
35.0
78
55
A-A
8.0
8.0
40
52
92
30
18
24
24
10
M5
Steel
28
95.0
90
65
A-A
10.0
10.0
48
62
92
35
20
28
28
15
M6
Steel
38
190.0
114
80
A-A
14.0
14.0
66
77
92
45
24
37
37
15
M8
Steel
42
265.0
126
95
A-A
15.0
15.0
75
92
92
50
26
40
40
20
M8
Steel
48
310.0
140
105
A-A
18.0
18.0
85
102
92
56
28
45
45
20
M8
Steel
55
410.0
160
120
A-A
18.0
18.0
98
117
92
65
30
52
52
20
M10
Steel
65
625.0
185
135
A-A
20.0
20.0
115
132
92
75
35
61
61
20
M10
Steel
75
1280.0
210
160
A-A
30.0
30.0
135
158
92
85
40
69
69
25
M10
Steel
90
2400.0
245
200
A-A
35.0
35.0
160
180
92
100
45
81
81
25
M10
Steel
100
3300.0
270
225
B-B
35.0
35.0
-
180
92
110
50
-
89
30
M12
Steel
RINGSPANN StS - WKE-D/ST
