DST120P1000000425(Q=152)
1/5
Type designation
TYP
Size
BG
Carriage length
Q [mm]
stroke
HUB [mm]
Carriage position
HUBST [mm]
Spindle
SP
Selection of screw
SPA
Choice of guide body profile
FPA
Choice of carriages
STA
Drive version
AV
Selection of screw
SAW
Ballscrew pitch accuracy
SGK
End play of ball nut
ASM
Basic length
L [mm]
Order number
CNSORDERNO
Data sheet
INFO
1
2
3
DST/K 120 P
120
152
200
0.00
Trapezoidal thread
right hand (Standard)
one shaft (locating bearing side)
18x4
only for Ballscrew
only for Ballscrew
225
DST120P1000000425(Q=152)
Product datasheet
DST/K 160 P
160
196
200
0.00
Trapezoidal thread
right hand (Standard)
one shaft (locating bearing side)
24x5
only for Ballscrew
only for Ballscrew
285
DST160P1000000485(Q=196)
Product datasheet
DST/K 200 P
200
256
200
0.00
Trapezoidal thread
right hand (Standard)
one shaft (locating bearing side)
32x6
only for Ballscrew
only for Ballscrew
340
DST200P1000000540(Q=256)
Product datasheet
MCA - Positioning system DST/DSK 120 P, 160 P, 200 P (Spindle drives)
