EB360R.MC-C.TM8A.AC6C1.14180N
1/5
Function
TYPE
Magnet rotor
ROT
Connection
CT
Typecode
TC
Article number
AN
Website
WS
EPLAN
EP
Voltagesupply
ET
Consumptiontyp.
CONS
Interface
INT
Material
MAT
ProtectionEN60529
PC
Operating Temperature
OT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Multiturn
ø12 mm, screw mount
Cable, open cable end, length 1 m
EB360.MC-C.S012.V4GC1.13120N
11266754
4.5...30 VDC
60 mA (5 VDC, w/o load) | 20 mA (24 VDC, w/o load)
SSI
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: stainless steel
IP 67 (sensor housing)
-40...+85 °C (see general information)
Multiturn
ø12 mm, screw mount
Flylead connector M12, 8-pin, length 300 mm
EB360.MC-C.S012.V4GJN.13120N
11266756
4.5...30 VDC
60 mA (5 VDC, w/o load) | 20 mA (24 VDC, w/o load)
SSI
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: stainless steel
IP 67 (sensor housing)
-40...+85 °C (see general information)
Multiturn
M8 x 8 mm, threaded screw
Cable, open cable end, length 1 m
EB360.MC-C.TM8A.V4GC1.13120N
11266755
4.5...30 VDC
60 mA (5 VDC, w/o load) | 20 mA (24 VDC, w/o load)
SSI
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: aluminium, anodised
IP 67 (sensor housing)
-40...+85 °C (see general information)
Multiturn
M8 x 8 mm, threaded screw
Flylead connector M12, 8-pin, length 300 mm
EB360.MC-C.TM8A.V4GJN.13120N
11266757
4.5...30 VDC
60 mA (5 VDC, w/o load) | 20 mA (24 VDC, w/o load)
SSI
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: aluminium, anodised
IP 67 (sensor housing)
-40...+85 °C (see general information)
Singleturn
ø12 mm, screw mount
Flylead connector M12, 8-pin, length 300 mm
EB360.SC-C.S012.V4GJN.13000N
11266753
4.5...30 VDC
60 mA (5 VDC, w/o load) | 20 mA (24 VDC, w/o load)
SSI
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: stainless steel
IP 67 (sensor housing)
-40...+85 °C (see general information)
Multiturn
ø12 mm, screw mount
Cable, open cable end, length 1 m
EB360R.MC-C.S012.AC6C1.14180N
11720912
10...30 VDC
20 mA (24 VDC, w/o load)
CANopen®
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: stainless steel
IP 69K (sensor housing)
-40...+85 °C (see general information)
Multiturn
ø12 mm, screw mount
Flylead connector M12, 5-pin, length 300 mm
EB360R.MC-C.S012.AC6HN.14180N
11266768
10...30 VDC
20 mA (24 VDC, w/o load)
CANopen®
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: stainless steel
IP 69K (sensor housing)
-40...+85 °C (see general information)
Multiturn
ø12 mm, screw mount
Flylead connector DEUTSCH DT04-4P, length 300 mm
EB360R.MC-C.S012.AC6VN.14180N
11266780
10...30 VDC
20 mA (24 VDC, w/o load)
CANopen®
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: stainless steel
IP 69K (sensor housing)
-40...+85 °C (see general information)
Multiturn
M8 x 8 mm, threaded screw
Cable, open cable end, length 1 m
EB360R.MC-C.TM8A.AC6C1.14180N
11724058
10...30 VDC
20 mA (24 VDC, w/o load)
CANopen®
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: aluminium, anodised
IP 69K (sensor housing)
-40...+85 °C (see general information)
Multiturn
M8 x 8 mm, threaded screw
Flylead connector M12, 5-pin, length 300 mm
EB360R.MC-C.TM8A.AC6HN.14180N
11266765
10...30 VDC
20 mA (24 VDC, w/o load)
CANopen®
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: aluminium, anodised
IP 69K (sensor housing)
-40...+85 °C (see general information)
Multiturn
M8 x 8 mm, threaded screw
Flylead connector DEUTSCH DT04-4P, length 300 mm
EB360R.MC-C.TM8A.AC6VN.14180N
11266767
10...30 VDC
20 mA (24 VDC, w/o load)
CANopen®
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: aluminium, anodised
IP 69K (sensor housing)
-40...+85 °C (see general information)
Multiturn
M8 x 8 mm, threaded screw
Cable, open cable end, length 1 m
EB360R.MC-C.TM8A.AC9C1.14180N
11266752
10...30 VDC
20 mA (24 VDC, w/o load)
SAE J1939
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: aluminium, anodised
IP 69K (sensor housing)
-40...+85 °C (see general information)
Multiturn
M8 x 8 mm, threaded screw
Flylead connector M12, 5-pin, length 300 mm
EB360R.MC-C.TM8A.AC9HN.14180N
11286808
10...30 VDC
20 mA (24 VDC, w/o load)
SAE J1939
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: aluminium, anodised
IP 69K (sensor housing)
-40...+85 °C (see general information)
Singleturn
ø12 mm, screw mount
Flylead connector M12, 5-pin, length 300 mm
EB360R.SC-C.S012.AC6HN.14000N
11266764
10...30 VDC
20 mA (24 VDC, w/o load)
CANopen®
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: stainless steel
IP 69K (sensor housing)
-40...+85 °C (see general information)
Singleturn
M8 x 8 mm, threaded screw
Cable, open cable end, length 1 m
EB360R.SC-C.TM8A.AC6C1.14000N
11274939
10...30 VDC
20 mA (24 VDC, w/o load)
CANopen®
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: aluminium, anodised
IP 69K (sensor housing)
-40...+85 °C (see general information)
Singleturn
M8 x 8 mm, threaded screw
Flylead connector M12, 5-pin, length 300 mm
EB360R.SC-C.TM8A.AC6HN.14000N
11274163
10...30 VDC
20 mA (24 VDC, w/o load)
CANopen®
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: aluminium, anodised
IP 69K (sensor housing)
-40...+85 °C (see general information)
Singleturn
M8 x 8 mm, threaded screw
Cable, open cable end, length 1 m
EB360R.SC-C.TM8A.AC9C1.14000N
11266751
10...30 VDC
20 mA (24 VDC, w/o load)
SAE J1939
Housing: PA10T / GF30 | Cable sheath: PUR | Magnet rotor: aluminium, anodised
IP 69K (sensor housing)
-40...+85 °C (see general information)
Baumer - EB360
| 订购编码 | 11724058 |
| Shorttext | Absolute encoder – bearingless |
| 上次修改 | 24.04.2026 06:54:40 |
