DCS-005-3-3
1/5
Size
SIZE
Torque
TKN [Nm]
Total length
L [mm]
Outside diameter
A [mm]
Keyway (DIN 6885)
N
Bore diameter ØH7
D1 [mm]
Bore diameter ØH7
D2 [mm]
Hub length
LN [mm]
Basic dimension
E [mm]
Basic dimension
K [mm]
Basic dimension
H [mm]
clamping screws (ISO 4762)
S
Installation torque per screw
TA [Nm]
Mass moment of inertia
J [kg cm²]
max. radial misalignment
KR [mm]
max. axial misalignment
KA [mm]
max. angular misalignment
KW [°]
Torsional stiffness
CT [Nm/rad]
1
2
3
4
5
6
7
8
9
10
11
12
005
0.6
16.70
16
3.0
3.0
7.85
1.00
2.50
4.8
M2
0.5
0.003
0.02
0.05
0.5
500
010
1.0
19.35
19
3.0
3.0
9.15
1.05
3.15
5.8
M2.5
1.1
0.006
0.02
0.10
1.0
1400
020
2.0
23.15
26
4.0
4.0
10.75
1.65
3.30
9.5
M2.5
1.1
0.024
0.02
0.15
1.0
3700
025
4.0
23.40
29
5.0
5.0
10.75
1.90
3.30
11.0
M2.5
1.1
0.037
0.02
0.19
1.0
5600
030
5.0
27.30
34
10.0
10.0
12.40
2.50
3.75
12.5
M3
1.9
0.082
0.02
0.20
1.0
8000
035
10.0
34.00
39
6.0
6.0
15.50
3.00
4.50
14.0
M4
4.1
0.184
0.02
0.25
1.0
18000
040
12.0
34.00
44
15.0
15.0
15.50
3.00
4.50
17.0
M4
4.1
0.293
0.02
0.30
1.0
20000
050
25.0
43.40
56
19.0
19.0
20.50
2.40
6.00
22.0
M5
8.5
0.990
0.02
0.40
1.0
32000
055
40.0
50.60
63
10.0
10.0
24.00
2.60
7.75
23.0
M6
15.0
1.880
0.02
0.42
1.0
50000
060
60.0
53.60
68
24.0
24.0
25.20
3.20
7.75
26.5
M6
15.0
2.690
0.02
0.45
1.0
70000
080
100.0
68.00
82
18.0
18.0
30.00
8.00
9.00
28.0
M8
30.0
7.110
0.02
0.55
1.0
140000
090
180.0
68.30
94
25.0
25.0
30.00
8.30
9.00
34.0
M8
30.0
12.400
0.02
0.65
1.0
100000
RINGSPANN StS - DCS
| 简短文本 | Disk Coupling - single cardanic version |
