CKK-110-NN-1-140-OF01-001-LSS-001-001-000-000-002-0-000-000-000-000-001
1/5
Order number
CNSORDERNO
Size
BG
Length
L [mm]
Stroke
S [mm]
Version
VER
Guide
GD
Lubrication
LUB
Drive
DR
Carriage
CA
Center distance
LW [mm]
Mechanical interface
MI
Motor attachment
MATT
Motor code
MCODE
1
2
CKK-110-NN-1-140-OF01-001-LSS-001-001-000-000-002-0-000-000-000-000-001
110
140
50
LSS : Standard lubrication
001 : Ball screw assembly 16x5, screw journal 11 mm
0
0 : without
000 : without motor attachment
0 : without motor
CKK-145-NN-1-170-OF01-001-LSS-021-001-000-000-002-0-000-000-000-000-001
145
170
60
LSS : Standard lubrication
021 : Ball screw assembly 20x5, screw journal 14 mm
0
0 : without
000 : without motor attachment
0 : without motor
Bosch Rexroth - CKK
| 简短文本 | Compact Module with ball screw assembly |
| 上次修改 | 05.05.2026 10:05:14 |
