IPRM 12I9504/S14
1/5
Type
TYPE
Dimension
DIM [mm]
Output circuit
OS
Output signal
OSI
Mounting type
MT
Connection types
CT
Typecode
TC
Article number
AN
Website
WS
EPLAN
EP
Measuring distance Sd
SD
Resolution (RMS)
RES
Linearity error
LE
Repeat accuracy (Sd)
RA
Temperature drift
TD
Housing material
MH
Material (sensing face)
MS
1
2
3
Cylindrical threaded
12
Current output
0 ... 20 mA
Quasi-flush
Connector M12
IPRM 12I9504/S14
11017454
0.5 … 1.5 mm
< 0.01 µm (stat. 10 Hz) | < 0.06 µm (dynam. 520 Hz) | < 0.004 µm (range center)
± 50 µm
< 1 µm
± 10 µm
Steel (9 SMn (Pb) 28/36)
Ceramic
Cylindrical threaded
12
Current output
0 ... 20 mA
Quasi-flush
Connector M12
IPRM 12I9505/S14
10128566
0 … 2 mm
< 0.012 µm (stat. 10 Hz) | < 0.065 µm (dynam. 520 Hz) | < 0.006 µm (range center)
± 60 µm
< 1 µm
± 10 µm
Steel (9 SMn (Pb) 28/36)
Ceramic
Cylindrical threaded
12
Current output
0 ... 20 mA
Quasi-flush
Connector M12
IPRM 12I9506/S14
11017453
0 … 3 mm
< 0.08 µm (stat. 10 Hz) | < 0.17 µm (dynam. 520 Hz) | < 0.013 µm (range center)
± 150 µm
< 1 µm
± 25 µm
Steel (9 SMn (Pb) 28/36)
Ceramic
Baumer Group - IPRM
| 订购编码 | 11017454 |
| Shorttext | Inductive high-precision displacement sensor |
| 上次修改 | 05.08.2025 12:47:10 |
