50-7-3557
1/5
PREVIEW
Reference
REF
Material
MATERIAL
Finish
FINISH
A
A [mm]
B
B [mm]
C
C [mm]
D
D [mm]
Note
NOTE
weight
WEIGHT [g]
Link to PINET website
WEB
1
50-7-3557
steel
raw
35
21.8
0.8
2.4
undrilled / headed pin
7.5
https://webstore.pinet-industrie.com/en/products/25541-small-hinges-with-4-knuckles.html
Pinet - 5073557
| 订购编码 | 50-7-3557 |
| Shorttext | Small hinges A |
| 上次修改 | 23.02.2024 14:11:14 |
| 单位 |
