Electric engineering, automation, process control engineering

Low-voltage switch technology

Relay and socket

Standard all-or-nothing relay

2910517 - PLC-RSC-120UC/21HC/MS

PHOENIX CONTACT

...

Relay and socket

Standard all-or-nothing relay

2910517 - PLC-RSC-120UC/21HC/MS

PHOENIX CONTACT 2910517

Expand Table

主变量

次变量

1/5

Product preview

PREVIEW

Product number of the Manufacturer

MANUID

Manufacturer Type Description

MANUTYPEDESC

Short Description

DESCSHORT

Long Description

DESCLONG

Manufacturer Name

MANUNAME

Delivery Time

DELTIME

International product number

INTNO

width

BAF016 [mm]

height

BAA020 [mm]

2910517

PLC-RSC-120UC/21HC/MS

Relay module

PLC-INTERFACE, consisting of a relay base and pluggable power contact relay with manual operation, integrated status LED, Screw connection, 1 changeover contact, Bridge rectifier, Input voltage: 120 V AC / 110 V DC

Phoenix Contact GmbH & Co. KG

4055626487410

13.9

显示压缩表示形式 (1 Produkt)

订购编码	2910517
Shorttext	Relay module
Longtext	PLC-INTERFACE, consisting of a relay base and pluggable power contact relay with manual operation, integrated status LED, Screw connection, 1 changeover contact, Bridge rectifier, Input voltage: 120 V AC / 110 V DC
上次修改	24.01.2025 18:33:35
单位

关键字

分类

CNS

CNSERPBASE Object Properties

Description long	PLC-INTERFACE, consisting of a relay base and pluggable power contact relay with manual operation, integrated status LED, Screw connection, 1 changeover contact, Bridge rectifier, Input voltage: 120 V AC / 110 V DC
Description short	Relay module
GTIN-Code	4055626487410
Order Number	2910517

CNSPHYPROP Physical Properties

ECLASS 14.0

27-37-16-01 标准全有或全无继电器

产品类型	PLC-RSC-120UC/21HC/MS
EAN代码	4055626487410
厂商产品编号	2910517
制造商名称	Phoenix Contact GmbH & Co. KG
使用规范	IEC 60947-5-1
附加链接地址	http://www.phoenixcontact.com/product/2910517
功率损耗规格的额定电流 [In］	10
每极功率损耗，取决于电流 [PlIp]	0.600
制造商产品说明	PLC-INTERFACE, consisting of a relay base and pluggable power contact relay with manual operation, integrated status LED, Screw connection, 1 changeover contact, Bridge rectifier, Input voltage: 120 V AC / 110 V DC
制造商产品名称	Relay module
制造商通用标识号	4063151
制造商 URI	www.phoenixcontact.com
损耗功率	0.600
通过认证	EAC

ECLASS 13.0

27-37-16-01 标准全有或全无继电器

切换触点的类型	Simple contact
最小额定控制电压Us（交流50Hz）	96
最小额定控制电压Us（交流60Hz）	96
最小额定控制电压Us（直流）	93.500
接触涂层的材料	without
标称电流	0.005
material of contact insert	Plastic
Contact material	AgNi
Product type	PLC-RSC-120UC/21HC/MS
EAN代码	4055626487410
厂商产品编号	2910517
制造商名称	Phoenix Contact GmbH & Co. KG
断开触点数量	0
转换器数量	1
闭合触点数量	0
使用规范	IEC 60947-5-1
address of additional link	http://www.phoenixcontact.com/product/2910517
Rated current [In] for the power loss specification	10
Power loss per pole, current-dependent [PlIp]	0.600
Manufacturer product description	PLC-INTERFACE, consisting of a relay base and pluggable power contact relay with manual operation, integrated status LED, Screw connection, 1 changeover contact, Bridge rectifier, Input voltage: 120 V AC / 110 V DC
Manufacturer product designation	Relay module
GLN of manufacturer	4063151
URI of manufacturer	www.phoenixcontact.com
高度	80
损耗功率	0.600
通过认证	EAC
深度	104
传动及功能	monostable
传动极性说明	poled
操纵方法	AC
带插槽的整体设备	Yes
LED显示	Yes
可拆端子	No
触点，强制进行	No
电路连接说明	Screw connection
宽度	13.9
保护方式IP	IP20

ETIM 10.0

EC001437 Switching relay

Type of switch contact	Simple contact
Rated control supply voltage AC 50 Hz	96
Rated control supply voltage AC 60 Hz	96
Rated control supply voltage DC	93.500
Material of contact surface	without
Nominal current	0.005
Material of contact insert	Plastic
Material contact	AgNi
Number of contacts as normally closed contact	0
Number of contacts as change-over contact	1
Number of contacts as normally open contact	0
Height	80
Depth	104
Drive, switching attitude	monostable
Drive, polarization	poled
Voltage type for actuating	AC
Complete with socket	Yes
With LED indication	Yes
With detachable clamps	No
With forced-guided contacts	No
Type of electric connection	Screw connection
Width	13.9
Degree of protection (IP)	IP20

ETIM 9.0

EC001437 Switching relay

Type of switch contact	Simple contact
Rated control supply voltage AC 50 Hz	96
Rated control supply voltage AC 60 Hz	96
Rated control supply voltage DC	93.500
Material of contact surface	without
Nominal current	0.005
Material of contact insert	Plastic
Material contact	AgNi
Number of contacts as normally closed contact	0
Number of contacts as change-over contact	1
Number of contacts as normally open contact	0
Height	80
Depth	104
Drive, switching attitude	monostable
Drive, polarization	poled
Voltage type for actuating	AC
Complete with socket	Yes
With LED indication	Yes
With detachable clamps	No
With forced-guided contacts	No
Type of electric connection	Screw connection
Width	13.9
Degree of protection (IP)	IP20
