PHOENIX CONTACT 1713088
1/5
Product preview
PREVIEW
Product number of the Manufacturer
MANUID
Manufacturer Type Description
MANUTYPEDESC
Short Description
DESCSHORT
Long Description
DESCLONG
Manufacturer Name
MANUNAME
Delivery Time
DELTIME
International product number
INTNO
width
BAF016 [mm]
height
BAA020 [mm]
1
1713088
PTSA 1,5/ 4-3,5-F RD WH NZ09
PCB terminal block
Printed circuit board terminal, nominal current: 8 A, rated voltage (III/2): 250 V, nominal cross section: 1.5 mm², number of potentials: 4, number of rows: 1, number of positions per row: 4, product range: PTSA 1,5, pitch: 3.5 mm, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, color: multicolored, Pin layout: Linear front pinning, Solder pin [P]: 3.5 mm, number of solder pins per potential: 1, type of packaging: packed in cardboard
Phoenix Contact GmbH & Co. KG
33
4046356088800
15.500
16.700
PHOENIX CONTACT - 1713088
| 订购编码 | 1713088 |
| Shorttext | PTSA 1,5/ 4-3,5-F RD WH NZ09 |
| 上次修改 | 11.02.2026 08:41:31 |
| 单位 |
分类
