PHOENIX CONTACT 1604242

Expand Table
EN
1/5
Product preview
PREVIEW
Product number of the Manufacturer
MANUID
Manufacturer Type Description
MANUTYPEDESC
Short Description
DESCSHORT
Long Description
DESCLONG
Manufacturer Name
MANUNAME
Delivery Time
DELTIME
International product number
INTNO
Without halogens
BAD656
protection type (NEMA)
AAW361
1
1604242
RC-Z2091
Cable gland
Cable gland, material for screw connection: Brass, nickel-plated, external cable diameter 6 mm ... 10 mm, shielding: no, connecting thread: Pg9, series: RC
Phoenix Contact GmbH & Co. KG
26
4046356248259
No
not available
显示压缩表示形式 (1 Produkt)
订购编码1604242
ShorttextCable gland
LongtextCable gland, material for screw connection: Brass, nickel-plated, external cable diameter 6 mm ... 10 mm, shielding: no, connecting thread: Pg9, series: RC
上次修改14.01.2025 06:40:25
单位

分类

CNS

CNSERPBASE Object Properties
Description longCable gland, material for screw connection: Brass, nickel-plated, external cable diameter 6 mm ... 10 mm, shielding: no, connecting thread: Pg9, series: RC
Description shortCable gland
GTIN-Code4046356248259
Order Number1604242
CNSPHYPROP Physical Properties

ECLASS 14.0

27-14-08-01 电缆压盖(电气安装)
保护度(IP),已安装IP65
最大密封范围10
最小密封范围6
防火性能(根据 UL94 标准)not available
产品类型RC-Z2091
EAN代码4046356248259
厂商产品编号1604242
制造商名称Phoenix Contact GmbH & Co. KG
附加链接地址http://www.phoenixcontact.com/product/1604242
连接螺纹类型PG
制造商产品说明Cable gland, material for screw connection: Brass, nickel-plated, external cable diameter 6 mm ... 10 mm, shielding: no, connecting thread: Pg9, series: RC
制造商产品名称Cable gland
保护等级(NEMA)not available
制造商通用标识号4063151
无铅No
用于铠装电缆No
内套最大密封值10
最小密封值 内垫6
防火符合 EN 45545-2 标准not available
卫生设计No
通过认证EAC

ECLASS 13.0

27-14-08-01 Cable gland (electrical installation)
保护度(IP),已安装IP65
mounting threadPg9
max. sealing range10
min. sealing range6
fire resistance (according to UL94)not available
Product typeRC-Z2091
EAN代码4046356248259
厂商产品编号1604242
制造商名称Phoenix Contact GmbH & Co. KG
address of additional linkhttp://www.phoenixcontact.com/product/1604242
type of connection threadPG
Manufacturer product descriptionCable gland, material for screw connection: Brass, nickel-plated, external cable diameter 6 mm ... 10 mm, shielding: no, connecting thread: Pg9, series: RC
Designeven
Manufacturer product designationCable gland
protection type (NEMA)not available
GLN of manufacturer4063151
lead freeNo
separable screw connectionNo
for armored cablesNo
max. sealing value inner jacket10
min. sealing value inner mat6
fire protection according to EN 45545-2not available
hygienic designNo
通过认证EAC
材料Brass, nickel-plated
原材料Metal film
无卤素No

ETIM 10.0

EC000441 Cable gland
Nominal thread size metric/PGPg9
Thread typePg9
Modeleven
Separable screw glandNo
MaterialBrass, nickel-plated
Material qualityMetal film
Halogen freeNo

ETIM 9.0

EC000441 Cable gland
Nominal thread size metric/PGPg9
Thread typePg9
Modeleven
Separable screw glandNo
MaterialBrass, nickel-plated
Material qualityMetal film
Halogen freeNo
