PHOENIX CONTACT
Elektro-, Automatisierungs- und Prozessleittechnik
Steckverbindersystem
Industriesteckverbinder
Rechtecksteckverbinder (Set)
1416354 - HC-STA-B10PT-BWSC-LS-M25-ELCAL
PHOENIX CONTACT
Industriesteckverbinder
Rechtecksteckverbinder (Set)
1416354 - HC-STA-B10PT-BWSC-LS-M25-ELCAL
1/5
1
1
2|0
3
4
4
0
0
0
0
0
0
0
0
0
0

PHOENIX CONTACT 1416354

Expand Table
1/5
Produktbild
PREVIEW
Artikelnummer des Herstellers
MANUID
Herstellertypbezeichnung
MANUTYPEDESC
Kurzbeschreibung
DESCSHORT
Langbeschreibung
DESCLONG
Internationale Artikelnummer
INTNO
Name des Herstellers
MANUNAME
Schutzart (IP, montiert)
AAC108
Breite
BAF016 [mm]
Höhe
BAA020 [mm]
Tiefe
BAB577 [mm]
1
1416354
HC-STA-B10PT-BWSC-LS-M25-ELCAL
Steckverbinder-Set
Steckverbinder-Set, Polzahl: 10, Anschlussart: Push-in-Anschluss, Anschlussquerschnitt: AWG 26- 14
4055626071251
Phoenix Contact GmbH & Co. KG
IP66
103.653979
112.483345
89.938903
显示压缩表示形式 (1 Produkt)
零部件信息
相似件
Request for quote (RFQ)
PHOENIX CONTACT - 1416354
订购编码1416354
ShorttextHC-STA-B10PT-BWSC-LS-M25-ELCAL
上次修改05.06.2026 18:56:29
单位
关键字

分类

CNS

CNSELEK|5|19 Mounting exclusion
Parent CLS_ID INST_ID||
CNSERPBASE Object Properties

ECLASS 14.0

27-44-01-13 矩形连接器（套）
最大连接导体截面积2.500 mm^2
最小连接导体截面积2.500 mm^2
产品类型HC-STA-B10PT-BWSC-LS-M25-ELCAL
EAN代码4055626071251
厂商产品编号1416354
制造商名称Phoenix Contact GmbH & Co. KG
使用规范not available
附加链接地址http://www.phoenixcontact.com/product/1416354
导线连接方法Push-in-Anschluss
电缆外径，最小值11 mm
电缆外径，最大17 mm
制造商产品说明Steckverbinder-Set, Polzahl: 10, Anschlussart: Push-in-Anschluss, Anschlussquerschnitt: AWG 26- 14
制造商产品名称Steckverbinder-Set
制造商通用标识号4063151
通过认证EAC, DNV
27-44-01-14 矩形连接器（用于现场组装）

ECLASS 13.0

27-44-01-13 Rectangular connector (set)
互锁类型Längsbügel
额定浪涌电压6 kV
最大连接导体截面积2.500 mm^2
最小连接导体截面积2.500 mm^2
有PE联接Ja
保护度(IP)，已安装IP66
最小工作温度-40 °C
最大工作温度100 °C
rated current16 A
Product typeHC-STA-B10PT-BWSC-LS-M25-ELCAL
EAN代码4055626071251
厂商产品编号1416354
制造商名称Phoenix Contact GmbH & Co. KG
使用规范not available
address of additional linkhttp://www.phoenixcontact.com/product/1416354
Conductor connection methodPush-in-Anschluss
External cable diameter, min.11 mm
External cable diameter, max.17 mm
极数10
Manufacturer product descriptionSteckverbinder-Set, Polzahl: 10, Anschlussart: Push-in-Anschluss, Anschlussquerschnitt: AWG 26- 14
Manufacturer product designationSteckverbinder-Set
GLN of manufacturer4063151
高度112.483345 mm
污染度3
通过认证EAC, DNV
深度89.938903 mm
宽度103.653979 mm
额定电压500 V
27-44-01-14 Rectangular connector (for field assembly)

ETIM 10.0

EC002636 Rectangular connector, set (industrial connector)
Type of lockingLängsbügel
Rated surge voltage6 kV
With protective conductorJa
Degree of protection (IP), mountedIP66
Operating temperature-40 °C
Rated current In16 A
Number of poles10
Height112.483345 mm
Pollution degree3
Depth89.938903 mm
Width103.653979 mm
Rated voltage500 V

ETIM 9.0

EC002636 Rectangular connector, set (industrial connector)
Type of lockingLängsbügel
Rated surge voltage6 kV
With protective conductorJa
Degree of protection (IP), mountedIP66
Operating temperature-40 °C
Rated current In16 A
Number of poles10
Height112.483345 mm
Pollution degree3
Depth89.938903 mm
Width103.653979 mm
Rated voltage500 V
