PHOENIX CONTACT
Information, communication and media technology
Network technology (computer communication)
Network component (industrial application)
Security router (wired, industrial application)
1357828 - FL MGUARD 2102
PHOENIX CONTACT
Security router (wired, industrial application)
1357828 - FL MGUARD 2102
1/5
1
1
2|0
3
4
4
0
0
0
0
0
0
0
0
0
0

PHOENIX CONTACT 1357828

Expand Table
1/5
Product preview
PREVIEW
Product number of the Manufacturer
MANUID
Manufacturer Type Description
MANUTYPEDESC
Short Description
DESCSHORT
Long Description
DESCLONG
Manufacturer Name
MANUNAME
Delivery Time
DELTIME
International product number
INTNO
net weight
AAF040 [kg]
certificate/approval
BAB392
1
1357828
FL MGUARD 2102
Router
Security-Router series, 2 RJ45 ports 10/100/1000 Mbps, degree of protection: IP20, Ambient temperature (operation): -20 °C ... 60 °C, Supply voltage range: 12 V DC ... 36 V DC, NAT, VPN, Product certified in accordance with IEC 62443-4-2, Simple stateful inspection firewall, safe isolation for PROFIsafe in accordance with IEC 61784-3-3
Phoenix Contact GmbH & Co. KG
5
4063151685737
0.310
CE-compliant
显示压缩表示形式 (1 Produkt)
零部件信息
相似件
Request for quote (RFQ)
PHOENIX CONTACT - 1357828
订购编码1357828
ShorttextFL MGUARD 2102
上次修改26.02.2026 18:33:50
单位
关键字

分类

CNS

CNSELEK|5|8|9 Supply voltage Function
IEC_81346_2_CODET
Function descriptionPower supply
Function NamePower Supply
Function short descriptionDefault Description
Symbol/Function NumberE000PS||1
IEC_81346_2_SUBCLASS_CODETA
CNSERPBASE Object Properties
CNSPHYPROP Physical Properties

ECLASS 14.0

19-17-04-06 安全路由器（有线、工业应用）
最大供电电压（直流）　24 V
最小供电电压（直流）24 V
产品类型FL MGUARD 2102
EAN代码4063151685737
厂商产品编号1357828
制造商名称Phoenix Contact GmbH & Co. KG
连接数量2
使用规范EN 61000-6-2:2005, cUL Listed, IEC 61000-4-2 (ESD), IEC 61000-4-3 (immunity to radiated interference), IEC 61000-4-4 (burst), IEC 61000-4-5 (surge), IEC 61000-4-6 (immunity to conducted interference)
附加链接地址http://www.phoenixcontact.com/product/1357828
制造商产品说明Security-Router series, 2 RJ45 ports 10/100/1000 Mbps, degree of protection: IP20, Ambient temperature (operation): -20 °C ... 60 °C, Supply voltage range: 12 V DC ... 36 V DC, NAT, VPN, Product certified in accordance with IEC 62443-4-2, Simple stateful inspection firewall, safe isolation for PROFIsafe in accordance with IEC 61784-3-3
VPN 隧道数量0
制造商产品名称Router
可进行功能扩展Yes
制造商通用标识号4063151
损耗功率2.880 W
通过认证CE-compliant
供电电压类型DC
安装方式Miscellaneous
保护方式IPIP20

ECLASS 13.0

19-17-04-06 Security router (wired, industrial application)
最大供电电压（直流）　24 V
最小供电电压（直流）24 V
Product typeFL MGUARD 2102
EAN代码4063151685737
厂商产品编号1357828
制造商名称Phoenix Contact GmbH & Co. KG
连接数量2
使用规范EN 61000-6-2:2005, cUL Listed, IEC 61000-4-2 (ESD), IEC 61000-4-3 (immunity to radiated interference), IEC 61000-4-4 (burst), IEC 61000-4-5 (surge), IEC 61000-4-6 (immunity to conducted interference)
address of additional linkhttp://www.phoenixcontact.com/product/1357828
Manufacturer product descriptionSecurity-Router series, 2 RJ45 ports 10/100/1000 Mbps, degree of protection: IP20, Ambient temperature (operation): -20 °C ... 60 °C, Supply voltage range: 12 V DC ... 36 V DC, NAT, VPN, Product certified in accordance with IEC 62443-4-2, Simple stateful inspection firewall, safe isolation for PROFIsafe in accordance with IEC 61784-3-3
Number of VPN tunnels0
Manufacturer product designationRouter
Functional expansion possibleYes
GLN of manufacturer4063151
损耗功率2.880 W
通过认证CE-compliant
供电电压类型DC
安装方式Miscellaneous
保护方式IPIP20
