1212173 - WIREFOX-D 16
PHOENIX CONTACT
Plant equipment, tool
Hand tool
Edge cutter, cutter
Wire stripper pliers
1212173 - WIREFOX-D 16
1
2|1
3
4
4
0
0
0
0
0
0
0
0
0
0

PHOENIX CONTACT 1212173

Expand Table
EN
Product preview
PREVIEW
Product number of the Manufacturer
MANUID
Manufacturer Type Description
MANUTYPEDESC
Short Description
DESCSHORT
Long Description
DESCLONG
Manufacturer Name
MANUNAME
Delivery Time
DELTIME
International product number
INTNO
Insulation present
BAD383
VDE tested
AAG615
ESD proved
AAG794
impact protection present
AAL858
1
1212173
WIREFOX-D 16
Stripping tool
Stripping tool, min. cross section: 4 mm², max. cross section: 70 mm², weight 75, black
Phoenix Contact GmbH & Co. KG
5
4046356454278
Yes
No
No
Yes
显示压缩表示形式 (1 Produkt)
零部件信息
Price Trend Risk
WIREFOX-D 16
标准代码1212173
描述WIREFOX-D 16
公司PHOENIX CONTACT
上次修改24.01.2025 18:01:05
单位
关键字
1212173,WIREFOX-D 16,PHOENIX CONTACT

CNS

CNSERPBASE Object Properties
Description longStripping tool, min. cross section: 4 mm², max. cross section: 70 mm², weight 75, black
Description shortStripping tool
GTIN-Code4046356454278
Order Number1212173

ECLASS 14.0

21-04-37-06 剥线钳
最大带材直径 (AWG)0
最小带材直径 (AWG)12
自动扳手No
产品类型WIREFOX-D 16
EAN代码4046356454278
厂商产品编号1212173
制造商名称Phoenix Contact GmbH & Co. KG
附加链接地址http://www.phoenixcontact.com/product/1212173
制造商产品说明Stripping tool, for stripping lines (specially for fiber optics lines) of Ø 4 - 16 mm
制造商产品名称Stripping tool
制造商通用标识号4063151
制造商 URIwww.phoenixcontact.com
产品的 URIhttp://www.phoenixcontact.com/product/1212173
最大横截面70
最小横截面4
净重75
顶部宽度15

ECLASS 13.0

21-04-37-06 剥线钳
VDE testedNo
grip casingplastic sleeve
ESD provedNo
jaw length0
max. strip diameter (AWG)0
min. strip diameter (AWG)12
max. strip range (diameter)16
min. strip range (diameter)4
max. strip range (cross-section)70
min. strip range (cross-section)4
automatic wrenchingNo
self adjustingNo
strip length adjustableNo
wire cutter presentNo
depth of notch adjustableYes
longitudinal section presentYes
impact protection presentYes
round edge presentYes
isolation protection (1000 V) presentNo
spiral cut possibleNo
Product typeWIREFOX-D 16
EAN代码4046356454278
厂商产品编号1212173
制造商名称Phoenix Contact GmbH & Co. KG
address of additional linkhttp://www.phoenixcontact.com/product/1212173
Manufacturer product descriptionStripping tool, for stripping lines (specially for fiber optics lines) of Ø 4 - 16 mm
Manufacturer product designationStripping tool
GLN of manufacturer4063151
URI of manufacturerwww.phoenixcontact.com
URI of the producthttp://www.phoenixcontact.com/product/1212173
长度131.5
头部高度28.7
最大横截面70
最小横截面4
绝缘Yes
净重75
手柄说明1-component
顶部宽度15

ETIM 9.0

EC002109 Wire stripper pliers
VDE testedNo
Handle coverplastic sleeve
ESD testedNo
Jaw length0
Strip range diameter16
Strip range cross-section70
Self-adjustingNo
Strip length adjustableNo
With wire cutterNo
Depth of notch adjustableYes
Longitudinal sectionYes
With impact protectionYes
Round edgeYes
Isolation protection 1000 VNo
Spiral cutNo
Length131.5
Head height28.7
InsulatedYes
Grip design1-component
