PHOENIX CONTACT 1212172

Expand Table
Produktbild
PREVIEW
Artikelnummer des Herstellers
MANUID
Herstellertypbezeichnung
MANUTYPEDESC
Kurzbeschreibung
DESCSHORT
Langbeschreibung
DESCLONG
Internationale Artikelnummer
INTNO
Name des Herstellers
MANUNAME
Isolation vorhanden
BAD383
VDE-geprüft
AAG615
ESD-geprüft
AAG794
Aufprallschutz vorhanden
AAL858
Schutzisolierung (1000 V) vorhanden
AAM090
1
1212172
WIREFOX-D SHIELD
Abisolierwerkzeug
Abisolierwerkzeug, Querschnitt min.: 16 mm², Querschnitt max.: 25 mm², Gewicht 100 g, schwarz
4046356454308
Phoenix Contact GmbH & Co. KG
Nein
Nein
Nein
Nein
Nein
显示压缩表示形式 (1 Produkt)
订购编码1212172
ShorttextAbisolierwerkzeug
LongtextAbisolierwerkzeug, Querschnitt min.: 16 mm², Querschnitt max.: 25 mm², Gewicht 100 g, schwarz
上次修改05.06.2026 18:23:17
单位

分类

CNS

CNSERPBASE Object Properties
Customs Tariff Number82032000
Description longAbisolierwerkzeug, Querschnitt min.: 16 mm², Querschnitt max.: 25 mm², Gewicht 100 g, schwarz
Description shortAbisolierwerkzeug
GTIN-Code4046356454308
Order Number1212172

ECLASS 14.0

21-04-37-06 剥线钳
最小带材直径 (AWG)6
自动扳手Nein
产品类型WIREFOX-D SHIELD
EAN代码4046356454308
厂商产品编号1212172
制造商名称Phoenix Contact GmbH & Co. KG
附加链接地址http://www.phoenixcontact.com/product/1212172
制造商产品说明Abisolierzange, zum Entmanteln von Leitungen für Kabelausschnitte, Leitungsabgriffe und Schirmanschlüsse Ø 8 mm ... 9 mm, bis Isolationsstärke 1,2 mm, Abisolierlänge ab: 20 mm
制造商产品名称Abisolierwerkzeug
制造商通用标识号4063151
制造商 URIwww.phoenixcontact.com
产品的 URIhttp://www.phoenixcontact.com/product/1212172
最大横截面25 mm^2
最小横截面16 mm^2
净重100 g
顶部宽度23 mm

ECLASS 13.0

21-04-37-06 剥线钳
VDE testedNein
grip casingKunststoffhüllen
ESD provedNein
jaw length30 mm
head width23 mm
min. strip diameter (AWG)6
max. strip range (diameter)9 mm
min. strip range (diameter)8 mm
max. strip range (cross-section)25 mm^2
min. strip range (cross-section)16 mm^2
automatic wrenchingNein
self adjustingJa
strip length adjustableNein
wire cutter presentNein
depth of notch adjustableNein
longitudinal section presentJa
impact protection presentNein
round edge presentNein
isolation protection (1000 V) presentNein
spiral cut possibleNein
Product typeWIREFOX-D SHIELD
EAN代码4046356454308
厂商产品编号1212172
制造商名称Phoenix Contact GmbH & Co. KG
address of additional linkhttp://www.phoenixcontact.com/product/1212172
Manufacturer product descriptionAbisolierzange, zum Entmanteln von Leitungen für Kabelausschnitte, Leitungsabgriffe und Schirmanschlüsse Ø 8 mm ... 9 mm, bis Isolationsstärke 1,2 mm, Abisolierlänge ab: 20 mm
Manufacturer product designationAbisolierwerkzeug
GLN of manufacturer4063151
URI of manufacturerwww.phoenixcontact.com
URI of the producthttp://www.phoenixcontact.com/product/1212172
长度166 mm
头部高度68 mm
最大横截面25 mm^2
最小横截面16 mm^2
绝缘Nein
净重100 g
手柄说明1-Komponenten
顶部宽度23 mm

ETIM 10.0

EC002109 Wire stripper pliers
VDE testedNein
Handle coverKunststoffhüllen
ESD testedNein
Jaw length30 mm
Head width23 mm
Strip range diameter9 mm
Strip range cross-section25 mm^2
Self-adjustingJa
Strip length adjustableNein
With wire cutterNein
Depth of notch adjustableNein
Longitudinal sectionJa
With impact protectionNein
Round edgeNein
Isolation protection 1000 VNein
Spiral cutNein
Length166 mm
Head height68 mm
InsulatedNein
Grip design1-Komponenten

ETIM 9.0

EC002109 Wire stripper pliers
VDE testedNein
Handle coverKunststoffhüllen
ESD testedNein
Jaw length30 mm
Head width23 mm
Strip range diameter9 mm
Strip range cross-section25 mm^2
Self-adjustingJa
Strip length adjustableNein
With wire cutterNein
Depth of notch adjustableNein
Longitudinal sectionJa
With impact protectionNein
Round edgeNein
Isolation protection 1000 VNein
Spiral cutNein
Length166 mm
Head height68 mm
InsulatedNein
Grip design1-Komponenten
