ETIM 9.0

EG000058 - Connectors

EC000438 - Contact insert for rectangular connectors

1066080 - HC-M-08-EMC-DSUB-F

ETIM 9.0

EG000058 - Connectors

EC000438 - Contact insert for rectangular connectors

1066080 - HC-M-08-EMC-DSUB-F

PHOENIX CONTACT 1066080

Expand Table

1/5

Produktbild

PREVIEW

Artikelnummer des Herstellers

MANUID

Herstellertypbezeichnung

MANUTYPEDESC

Kurzbeschreibung

DESCSHORT

Langbeschreibung

DESCLONG

Internationale Artikelnummer

INTNO

Name des Herstellers

MANUNAME

Breite

BAF016 [mm]

Höhe

BAA020 [mm]

Tiefe

BAB577 [mm]

Zertifikat/Zulassung

BAB392

1066080

HC-M-08-EMC-DSUB-F

Steckverbinder

Steckverbinder, Polzahl: 8, Leistungskontakte: 0, Steuerkontakte: 8, Buchse, Crimpanschluss, 48 V, 5 A, 0,09 mm² ... 0,52 mm², Leitungsaußendurchmesser:3 mm ... 9,5 mm, Anwendung: Daten/Signal

4055626727981

Phoenix Contact GmbH & Co. KG

19.760

18.83

45.9

EAC

显示压缩表示形式 (1 Produkt)

订购编码	1066080
Shorttext	Steckverbinder
Longtext	Steckverbinder, Polzahl: 8, Leistungskontakte: 0, Steuerkontakte: 8, Buchse, Crimpanschluss, 48 V, 5 A, 0,09 mm² ... 0,52 mm², Leitungsaußendurchmesser:3 mm ... 9,5 mm, Anwendung: Daten/Signal
上次修改	05.06.2026 19:00:46
单位

分类

CNS

CNSERPBASE Object Properties

Customs Tariff Number	85389099
Description long	Steckverbinder, Polzahl: 8, Leistungskontakte: 0, Steuerkontakte: 8, Buchse, Crimpanschluss, 48 V, 5 A, 0,09 mm² ... 0,52 mm², Leitungsaußendurchmesser:3 mm ... 9,5 mm, Anwendung: Daten/Signal
Description short	Steckverbinder
GTIN-Code	4055626727981
Order Number	1066080

ECLASS 14.0

27-44-02-05 工业插头连接器接触部分

产品类型	HC-M-08-EMC-DSUB-F
EAN代码	4055626727981
厂商产品编号	1066080
制造商名称	Phoenix Contact GmbH & Co. KG
使用规范	not available
附加链接地址	http://www.phoenixcontact.com/product/1066080
尺寸	not relevant
联系类型	turned
制造商产品说明	Steckverbinder, Polzahl: 8, Leistungskontakte: 0, Steuerkontakte: 8, Buchse, Crimpanschluss, 48 V, 5 A, 0,09 mm² ... 0,52 mm², Leitungsaußendurchmesser:3 mm ... 9,5 mm, Anwendung: Daten/Signal
制造商产品名称	Steckverbinder
制造商通用标识号	4063151
制造商 URI	www.phoenixcontact.com
通过认证	EAC

ECLASS 13.0

27-44-02-05 工业插头连接器接触部分

额定浪涌电压	0.800 kV
插入式触点的直径	1 mm
触点设计	Buchse
无触点的接触式插头	Ja
最大连接导体截面积（多股线）	0.520 mm^2
最小连接导体截面积（多股线）	0.090 mm^2
有线路保护	Nein
有PE联接	Nein
接触涂层的材料	Gold
触点材料	sonstige Kupferlegierungen
最小工作温度	-40 °C
最大工作温度	85 °C
过电压种类	III
rated current	5 A
material connector of connector insert	Thermoplast
Product type	HC-M-08-EMC-DSUB-F
EAN代码	4055626727981
厂商产品编号	1066080
制造商名称	Phoenix Contact GmbH & Co. KG
使用规范	not available
address of additional link	http://www.phoenixcontact.com/product/1066080
Conductor connection method	Crimpanschluss
Size	not relevant
Insertion cycles, min.	500
Contact type	turned
Number of power contacts	0
Number of control contacts	8
极数	8
Manufacturer product description	Steckverbinder, Polzahl: 8, Leistungskontakte: 0, Steuerkontakte: 8, Buchse, Crimpanschluss, 48 V, 5 A, 0,09 mm² ... 0,52 mm², Leitungsaußendurchmesser:3 mm ... 9,5 mm, Anwendung: Daten/Signal
Manufacturer product designation	Steckverbinder
GLN of manufacturer	4063151
URI of manufacturer	www.phoenixcontact.com
高度	18.83 mm
最高环境温度	85 °C
污染度	3
通过认证	EAC
深度	45.9 mm
绝缘材料的可燃性等级（根据UL 94)	V0
移动最大导体横截面	0.520 mm^2
移动最小导体横截面	0.090 mm^2
宽度	19.760 mm
额定电压	48 V

ETIM 10.0

EC000438 Contact insert for rectangular connectors

Rated surge voltage	0.800 kV
Diameter plug-in contact	1 mm
Contact type	Buchse
Contact insert without contacts	Ja
Connectable conductor cross section multi-wired	0.520 mm^2
With wire protection	Nein
With protective conductor	Nein
Material of contact surface	Gold
Material contact	sonstige Kupferlegierungen
Operating temperature	-40 °C
Over voltage category	III
Rated current In	5 A
Material connector insert	Thermoplast
Type of electric connection	Crimpanschluss
Min. number of insertion cycles	500
Number of power contacts	0
Number of control contacts	8
Number of poles	8
Height	18.83 mm
Ambient temperature	85 °C
Pollution degree	3
Depth	45.9 mm
Inflammability class of insulation material according to with UL94	V0
Connectable conductor cross section fine-strand without cable end sleeve	0.520 mm^2
Width	19.760 mm
Rated voltage	48 V

ETIM 9.0

EC000438 Contact insert for rectangular connectors

Rated surge voltage	0.800 kV
Diameter plug-in contact	1 mm
Contact type	Buchse
Contact insert without contacts	Ja
Connectable conductor cross section multi-wired	0.520 mm^2
With wire protection	Nein
With protective conductor	Nein
Material of contact surface	Gold
Material contact	sonstige Kupferlegierungen
Operating temperature	-40 °C
Over voltage category	III
Rated current In	5 A
Material connector insert	Thermoplast
Type of electric connection	Crimpanschluss
Min. number of insertion cycles	500
Number of power contacts	0
Number of control contacts	8
Number of poles	8
Height	18.83 mm
Ambient temperature	85 °C
Pollution degree	3
Depth	45.9 mm
Inflammability class of insulation material according to with UL94	V0
Connectable conductor cross section fine-strand without cable end sleeve	0.520 mm^2
Width	19.760 mm
Rated voltage	48 V
